2.00mm Pitch Wire To Board Connectors series product

64

2.00mm Pitch Wire To Board Connectors series product

Product Description 2.00mm Pitch Wire To Board ConnectorsZOOKE2006 SPECIFICATIONS Current rating:2A AC/DC Voltage rating:250V AC/DC Withstanding voltage:500V AC/miuute. Contact resistance:20MΩ Max. Insulation resistance:1000MΩ Min. Temperature range:-40℃~+105℃ Wire range:AWG 24#~28#     Item Material Pin QTY Housing PA66 UL94V-0 02~16/2*1~2*30 1000Pcs/Bag Wafer PA66 UL94V-0 02~16/2*1~2*30 1000Pcs/Reel Terminal Phosphor Bronze - 10,000Pcs/Reel Wire to board Connectors with a 2.0mm pitch have become increasingly popular in the electronics industry due to their compact size and high reliability. A wire to board connector is a type of electrical connector that allows for the connection of wires to a printed circuit board (PCB). These connectors are commonly used in applications where a durable and secure connection between wires and the PCB is required.   The 2.0mm pitch refers to the distance between each pin or contact in the…
