3 Way Normally Open Solenoid Valve 1/8'' 1/4''
3 Way Normally Open Solenoid Valve 1/8'' 1/4'' The multi-purpose 3/2 way direct acting solenoid valves are mainly suitable in the neutral gaseous and liquid fluid pipeline automatically control. It is suitable the medium of gas, water, oil, vacuum, steam. Can be operated with zero pressure difference & circulation direction is random. Product Features: 1. Working Medium: Air, Water, Steam, Oil, Gas, Vaccum, etc. 2. Working Pressure Range: 0 to 1 MPa (See the parameter table below for details) 3. Medium Temperature Range: NBR (-10 to +80℃), EPDM (-30 to +120℃), FKM (-30 to +150℃) 4. Port Size: 1/8'', 1/4'' 5. Orifice Size: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 4.0mm 6. Body Material: Brass, Stainless Steel 7. Seal Material: NBR, EPDM, FKM 8. Function: 3 Way Normally Closed, 3 Way Normally Open, Universal 9. Operation: Direct Acting 10. Voltage Option: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz) Overall Dimension of VX Series Solenoid Valve:…
